TX8 Radio Controller
- VAT fees will be added to orders bound for EU member states.
- Batteries can't be shipped separately, please purchase batteries with Radio units.
- Customized products require a 40-day lead time and no refunds can be made after the order is placed.
Specification
- Brand: Radiomaster
- Item No.: TX8
- Size: 158 x 150 x 58mm
- Weight: 338g (without battery)
- Color: Black
- Transmission frequency: 2.400GHZ-2485GHZ
- Transmitter Module: Four in One High Frequency Module (CC2500 CYRF6936 A7105 NRF2401)
- Transmit power: maximum 22dbm (transmit power adjustable)
- Antenna gain: 2db (detachable antenna, easy modification)
- Working current: 88Ma@8.4V
- Working voltage: DC4.5-DC18V
- Remote control distance:> 2km @ 22dbm
- Open source firmware
- Number of channels: up to 12 channels (depending on the receiver)
- Display: back lit LCD display, 128 * 64 resolution
- Rocker way: non-contact 3D space vector Hall joystick
- JR/FrSKY compatible module bay on rear side
- Upgrade method: USB online upgrade
Support Protocols
Walkera full range
DSM2/X full range
Flysky and Flysky 2A
FrSKY
FUTABA s-fhss full range
WL Toy series, Hubsan series, Esky series and many more (Currently a total of more than 40 supported protocols)
Uses open source software with continued support and development, adding new protocols regularly.
Features
* Built in four-in-1 RF Module (CC2500 CYRF6936 A7105 NRF2401).
* The TX8 is shipped with Deviation TX software installed as standard
* TX8 Plus back lit LCD display, Bright display works even in direct sunlight.
* Non-contact 3D space vector Hall remote sensing Gimbals
* JR/FrSKY compatible module bay on rear side.
* USB online firmware upgrade.
* Transmission power adjustable to adapt to different location requirements.
* Detachable antenna, easy to change.
* Ultra-low power consumption, longer battery life.
* Up to 12 channels of output (depending on the receiver)
* Wide voltage input (2s lipo recommended).
* Multilingual menu.
* Vibration reminder function.
* Support telemetry (depending on the receiver).
Package Includes
- 1 * TX8 Radio Controller
